Efficient Aquaphor S800 P1 Station with KDF85 Media – Comprehensive Water Treatment
Aquaphor S800 P1 with KDF85 is a highly efficient, compact water treatment station, designed for single-family homes with increased water demand. This device is a powerful combination of the classic S800 model's functions (effective softening, iron, and manganese removal) with the unique properties of active KDF85 media. This system absolutely eliminates the problem of hard water and effectively removes iron and manganese (up to 10 mg/l). Additionally, it creates a reliable protective barrier against dangerous chemical and microbiological contaminants in the installation.
The secret to the exceptional effectiveness of the P1 version lies in the use of innovative, copper-zinc KDF85 (Kinetic Degradation Fluxion) media. It possesses natural bacteriostatic properties, preventing the proliferation of microorganisms inside the tank. What's more, KDF85 excellently removes hydrogen sulfide (responsible for the "rotten egg" smell), reduces chlorine, and eliminates heavy metals. In combination with the patented flow distributor, which completely eliminates the formation of stagnant zones (dead zones), water evenly rinses the entire media, drastically increasing the efficiency and precision of filtration.
The Aquaphor S800 P1 model also guarantees economy at the highest level. The integrated intelligent controller automatically optimizes rinsing cycles based on current water consumption. This intelligent regeneration means that the device uses up to 30% less salt and water compared to standard market systems. The entire unit is enclosed in an extremely durable construction – the pressure vessel is made of homogeneous glass-filled composite, ensuring its trouble-free and safe operation for over 10 years.
| Parametry techniczne | |
|---|---|
| Wymiary, dł. x szer. x wys | 485 mm, 414 mm, 706 mm |
| Zakres filtracji | Water hardness, Iron (Fe), Manganese (Mn), Hydrogen sulfide (H₂S) |
| Typ urządzenia | Multifunction docking station |
| Pojemność zbiornika soli | 25 g |
| Pojemność złoża | 23 mL |
| Przepływ roboczy, m³/h | 1.5 |
| Maksymalne ciśnienie, bar | 7.0 |
| Min ciśnienie, Bar | 1.4 |
| Dla ilu osób | 1-3 |
| Waga | 43 kg |
| Gwarancja na urządzenie | 2 years |
Collapsible content
Key Features
Technical Data
| Parametr | Wartość |
|---|---|
| Maximum capacity, g | 1680 |
| Maximum compensated hardness, mg/l | 1380 |
| Maximum concentration of dissolved iron and manganese, mg/l | 12 |
| Minimum pH value | 6 |
| Water and ambient temperature, °C | +5...+38 |
| Water pressure, bar | 1.4-7.0 |
| Minimum backwash water flow, l/min | 7.6 |
| Maximum flow to sewer during regeneration, l/min | 9.1 |
| Nominal/maximum flow, l/min | 25/38 |
| Pressure loss at flow 22.7 l/min, bar | 10 |
| Performance in HE mode, kg salt / g hardness | 1.1/670 |
| Performance in HC mode, kg salt / g hardness | 3.0/1406 |
| Maximum capacity in AU mode, kg salt / g hardness | 5.4/1680 |
| Regeneration method | Intelligent based on the water meter |
| Power options | 12 VAC, 50/60 Hz, 0.015 kWh |
| Connections (NPT) | 1" (NPT) |
| Minimum diameter of drain pipe, mm (inches) | 16 (5/8) |
| Filter tank dimensions (diameter x height) mm | 267×584 |
| Height, cm | 70.1 |
| Base, cm | 40.4×48.5 |
| Gross weight, kg | 43 |
| SuperFine ion exchange resin, l | 23 |
| Quartzite (optional) kg | 0.8 |
| or KDF85, l (Only for S550 P1. version) | 0.35 |
AQUAPHOR water treatment technology. How it works.
Aquaphor S800 P1 with KDF85 | Water treatment station PDF
The composition of the set
| 1-Complete softener | 1 pc |
| 2-Overflow connector | 1 pc |
| 3-Drain hose D=16 mm, L=2.5 m | 1 pc |
| 4-Flexible hose 1" to 3/4" with O-rings, stainless steel | 2 pcs |
| 5-12 VAC power supply | 1 pc |
| 6-Controller | 1 pc |
Feedwater requirements
| Charakterystyka | Wartość |
|---|---|
| Hardness, dH* | ≤ 78 |
| Bivalent iron content, mg/l* | ≤ 12 |
| Trivalent iron content, mg/l | ≤ 0.3 |
| Manganese content, mg/l* | ≤ 3 |
| pH | 6 to 9 |
| Temperature, °C | from +5 to +38 |
| Oil product content, mg/l | ≤ 1 |
| Hydrogen sulfide, mg/l | ≤ 0.03 / ≤ 1 |
| Permanganate index, mgO₂/l | ≤ 5 |
| Silicon, mg/l | ≤ 10 |
Intelligent Regeneration (Savings up to 30%)
Patented flow divider
Comprehensive Action (Softening + Iron Removal)
Armored construction (Durability 10+ years)
